Scrubbing Java Heap Dumps

Heap Dump Analysis

A couple of months ago I was asked about tooling that could analyze large heap dumps. The question prompted me to write jheapo, a tool that not only was built to analyze large heap dumps but also to support a more modern set of queries that are absent from the usual suspects. It also lead me to one of the biggest obstacles to being able to perform an analysis, privacy. A heap dump can contain a ton of private data.

Every byte[] could include sensitive data that you can’t hand over to a third party. This could include customer names, email addresses, credit-card numbers, session tokens, the odd password that ended up in a char[] or even worse, private medical information. A lot of this data sits in byte[] or char[]. Even more obscure, your class and method names which are also in the heap dump, may reveal how the application is structured creating concerns about potential company secrets. In short, the privacy concerns, once realized, are the biggest reason why I end up performing heap dump analysis on site instead of in my home office. JScrub solves this problem by creating a copy of your heap dump with all of the sensitive data anonymized.

A Solution

JScrub rewrites a heap dump, replacing the contents of primitive arrays with random data of exactly the same length. Data that is repeated is replaced with the same random data. Because nothing changes, the scrubbed heap dump is structurally identical to the input: same object graph, same instance counts, same retained sizes, same everything — only the contents of the primitives and primitive arrays are replaced. An analyzer (I use jheapo) sees an identical heap without the secrets.

A few properties I cared about:

• Cardinality is preserved. If a value appears 10,000 times, its scrubbed replacement appears 10,000 times. “Why do I have a million copies of the same string?” is still answerable after scrubbing.
• It’s reversible. Every substitution goes into a key file that the dump’s owner keeps. Find something interesting in the scrubbed dump, and the key maps it back to the real value. The scrubbed dump goes where it needs to be whereas the key never leaves home.
• Names stay readable — unless you say otherwise. JDK, Jakarta/JEE, and framework class/field/method names aren’t secrets and they make analysis readable. If your own class and field names are sensitive, you can obfuscate those too (more below).

Getting it

Grab the jar from the releases page. It’s self-contained; you just need a Java 25+ runtime. One jar drives everything:

java -jar jscrub-0.1.0.jar --help

(There are also -dist archives with jscrub/jdescrub/jresolve launcher scripts, and native bundles that ship their own runtime if you’d rather not install Java.)

Scrubbing a dump

-C scrubs char[], -B scrubs byte[]. On a modern JDK you almost always want both, since strings live in byte[]:

java -jar jscrub-0.1.0.jar scrub -C -B myapp.hprof

You get two files:

• myapp_scrub.hprof — same size as the original, safe to share.
• myapp_scrub.hprof.scrubkey — the reversal key. Keep this private.

Open the scrubbed dump in your analyzer of choice and everything looks normal — the histogram, the dominator tree, the duplicate-string report — except the actual string values are gibberish.

Getting your data back

Two ways to undo it, both using the key.

Reconstruct the whole original dump, byte-for-byte:

java -jar jscrub-0.1.0.jar descrub myapp_scrub.hprof myapp_scrub.hprof.scrubkey

Or — more useful in practice — take a finding from your analysis (say, the top duplicated string) and map it back to the real value:

java -jar jscrub-0.1.0.jar resolve --min-len 8 myapp_scrub.hprof.scrubkey findings.txt

Though the plan is to have JScrub decode any report this feature is currently restricted to JHeapo output.

Hiding class names too

Sometimes the class names themselves are the sensitive part — they leak your internal architecture, product names, unreleased features. Put a jscrub.conf together and point -f at it:

// jscrub.conf — obfuscate my proprietary classes, leave the rest readable
com.acme.billing.**
com.acme.model.*

java -jar jscrub-0.1.0.jar scrub -C -B -f jscrub.conf myapp.hprof

com.acme.billing.CreditCard becomes something like xyz.abcdef.Ghijklmno — same length, same shape, package structure intact so your analyzer still groups things sensibly, and it’s in the key so you can reverse it. The rules are just wildcards, no regex: * for one segment, ** to recurse into sub-packages.

Where it’s going

The current release scrubs char[]/byte[] and obfuscates class names. Still on the list: obfuscating field and method names, and a few of the other primitive types. It’s source-available — have a look, and let me know what breaks.
